Description
Specifications
Frequency range： 300kHz
Transmitting beam: 150°X 1.28°
Receiving beam: 1.28°X 30°
Transmitting array type / number of elements Circular linear array elements/56
Receiving array type/number of elements
Linear array/80
Receiving array is arranged perpendicular to transmitting array in the pattern of T to make transmitting multi-beam normal for receiving multi-beams
Application & Features
Multi-beam surveying sonar and profiling side-scanning sonar in shallow water (Circuits not included in the assembly);
Custom options available
